Deere 2120
Contents:
Production | |
| Manufacturer: | John Deere |
| Factories: | Mannheim, Baden-Württemberg, Germany |
| Mexico | |
John Deere 2120 Power | |
| Engine: | 68 hp 50.7 kW |
| PTO (claimed): | 60 hp 44.7 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Final drives: | planetary |
| Differential lock: | mechanical rear |
| Cab: | Open operator station. Cab optional. |
| Transmissions: | 8-speed gear |
| 16-speed two-speed power shift | |
Hydraulics | |
| Type: | closed center |
| Pump flow: | 12.4 gpm 46.9 lpm |
Tractor hitch | |
| Rear Type: | II |
| Rear lift: | 4498 lbs 2040 kg |
Power Take-off (PTO) | |
| Rear RPM: | 540 |
2120 Serial Numbers | |
| Location: | Serial number plate on the right side of the 2120 frame, above the front axle. |
Engine Detail | |
| John Deere | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 219 ci 3.6 L |
| Bore/Stroke: | 4.02x4.33 inches 102 x 110 mm |
| Power: | 68 hp 50.7 kW |
| Fuel system: | direct injection |
| Rated RPM: | 2500 |
| Torque: | 51.3 lb-ft 69.6 Nm |
| Torque RPM: | 1500 |
Dimensions | |
| Wheelbase: | 86 inches 218 cm |
| Length: | 142 inches 360 cm |
| Height: | 96.5 inches 245 cm |
| Weight: | 6615 lbs 3000 kg |
