Cockshutt 2150
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Cockshutt |
| Type: | Row-Crop tractor |
| Factory: | Charles City, Iowa, USA |
| Original price: | $13,800 (1969) |
Cockshutt 2150 Power | |
| PTO (claimed): | 131 hp 97.7 kW |
| Drawbar (tested): | 109.51 hp 81.7 kW |
| PTO (tested): | 131.48 hp 98.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | planetary |
| Steering: | power |
| Brakes: | independent dry disc |
| Cab: | Open operator station. Cab optional with air-conditioning. |
| Transmissions: | 6-speed unsynchronized gear |
| 18-speed partial powershift | |
Tractor hitch | |
| Rear Type: | III |
| Control: | position and draft control |
| Rear lift (at 24"/610mm): | 6000 lbs 2721 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 1000 |
| 540/1000 | |
2150 Serial Numbers | |
| 1968: | 204480 |
| 1969: | 212554 |
| Final: | 216595 |
Engine Detail | |
| Oliver-Hercules | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 478 ci 7.8 L |
| Bore/Stroke: | 4.5625x4.875 inches 116 x 124 mm |
| Air cleaner: | dual dry type |
| Compression: | 18.0:1 |
| Rated RPM: | 2400 |
| Firing order: | 1-5-3-6-2-4 |
| Starter volts: | 12 |
| Oil capacity: | 19 qts 18.0 L |
| Coolant capacity: | 28 qts 26.5 L |
Dimensions | |
| Wheelbase: | 97.7 inches 248 cm |
| Length: | 162.3 inches 412 cm |
| Height (steering wheel): | 85.5 inches 217 cm |
| Operating weight: | 12,990 lbs 5892 kg |
| Ballasted weight: | 21,125 lbs 9582 kg |
| Ground clearance: | 18.9 inches 48 cm |
| 2WD Front tread: | 60 to 80 inches 152 to 203 cm |
| 4WD Front tread: | 66/70.75/80 inches 167/179/203 cm |
| 2WD Rear tread: | 61 to 91 inches 154 to 231 cm |
| 4WD Rear tread: | 61.5 to 111.5 inches 156 to 283 cm |
