Cletrac BG

Production: 1937 - 1951

Production
Manufacturer:	Cletrac
Type:	Agricultural Crawler tractor
Factory:	Cleveland, Ohio, USA

Variants
gasoline
diesel
BGH:	hillside

Cletrac BG Power
Drawbar (claimed):	38 hp 28.3 kW
Belt (claimed):	50 hp 37.3 kW
Plows:	4
Drawbar (tested):	28.27 hp 21.1 kW
Belt (tested):	39.07 hp 29.1 kW

Mechanical
Chassis:	crawler
Cab:	Open operator station.
Transmission:	4-speed gear

BG Serial Numbers
1937:	2C000
1938:	2C452
1939:	2C578
1940:	2C780
1941:	2C338
1942:	2C654
1943:	2C738
1944:	-----
1945:	6C0000
1946:	8C370
1947:	9C062
1948:	10C238
1949:	11C458
1950:	11C950
1951:	12C229

Engine Detail
Hercules
gasoline
6-cylinder
liquid-cooled
Displacement:	282 ci 4.6 L
Bore/Stroke:	3.75x4.25 inches 95 x 108 mm
Air cleaner:	oil bath
Rated RPM:	1400
Starter type:	electric

Transmission
Type:	gear
Gears:	4 forward and 2 reverse
Clutch:	dry

Dimensions
Length:	116.5 inches 295 cm
Width:	60.125 inches 152 cm
Height:	59 inches 149 cm
Weight:	8775 lbs 3980 kg
BG Gauge:	44 inches 111 cm
BGH Gauge:	52 inches 132 cm
