Claas Elios 240

Production: 2014 - 2020

Production
Manufacturer:	Claas
Type:	Utility tractor

Claas Elios 240 Power
Engine:	96.6 hp 72.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS. Cab available with air-conditioning.
Transmission:	24-speed power shuttle

Hydraulics
Valves:	2 to 4
Pump flow:	15.6 gpm 59.0 lpm
22.5 gpm 85.2 lpm *Optional

Tractor hitch
Rear lift:	7143 lbs 3240 kg
Front lift:	6173 lbs 2800 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/540E
540/1000*Optional
Front PTO:	independent*Optional
Front RPM:	540E
1000

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
FPT
turbocharged intercooled diesel
4-cylinder 8-valve
liquid-cooled
Displacement:	207.5 ci 3.4 L
Bore/Stroke:	3.90x4.33 inches 99 x 110 mm
Emissions:	Stage IIIB
Power:	96.6 hp 72.0 kW
Rated RPM:	2300
Torque:	299.5 lb-ft 406.1 Nm
Torque RPM:	1600
Starter:	electric
Starter volts:	12

Transmission
Transmission:	TWINSHIFT REVERSHIFT
Type:	power shuttle
Gears:	24 forward and 12 reverse
Two-speed power shift with power shuttle.

Dimensions
Wheelbase:	84.8 inches 215 cm
Length:	150.2 inches 381 cm
Height (cab):	93.3 inches 236 cm
Weight:	7297 lbs 3309 kg
Max weight:	11244 lbs 5100 kg
