Claas Atles 946

Production: 2005

Production
Manufacturer:	Claas

Claas 946 Power
Engine:	282 hp 210.3 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	standard with A/C
Transmission:	18-speed

Hydraulics
Total flow:	29.1 gpm 110.1 lpm

Tractor hitch
Rear lift:	26,460 lbs 12002 kg

Power Take-off (PTO)
Rear RPM:	750/1000

Engine Detail
Deutz Deutz BF6L1013FC
intercooled turbocharged
6-cylinder
Displacement:	436.4 ci 7.2 L
Bore/Stroke:	4.252x5.118 inches 108 x 130 mm
Power:	282 hp 210.3 kW
Rated RPM:	2000
Torque:	811.4 lb-ft 1100.3 Nm
Torque RPM:	1500

Transmission
Gears:	18 forward and 8 reverse

Dimensions
Wheelbase:	119.7 inches 304 cm
Length:	200.4 inches 509 cm
Height:	128.0 inches 325 cm
Weight:	19,902 lbs 9027 kg
