Chery RK504
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Chery |
| Type: | Utility tractor |
| Factory: | China |
Variants | |
| 2WD | |
| 4WD | |
| low-profile |
Chery RK504 Power | |
| Engine (gross): | 50 hp 37.3 kW |
| PTO (claimed): | 42.5 hp 31.7 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | mechanical rear |
| Steering: | hydraulic power |
| Brakes: | pneumatic brake optional |
| Cab: | Open operator station. Optional ROPS. Optional canopy. Cab available with optional air-conditioning. |
| Transmissions: | 12-speed shuttle |
| 8-speed gear | |
Tractor hitch | |
| Control: | position, draft, and float control |
| Rear lift (at 24"/610mm): | 1911 lbs 866 kg |
| Drawbar: | fixed drawbar |
| swinging drawbar optional | |
Power Take-off (PTO) | |
| Rear PTO: | live |
| Rear RPM: | 540/760 |
| 540/1000 (optional) | |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Xin Chai 498BT | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 193.3 ci 3.2 L |
| Bore/Stroke: | 3.858x4.134 inches 98 x 105 mm |
| Power (gross): | 50 hp 37.3 kW |
| Fuel system: | direct injection |
| Air cleaner: | oil bath |
| Rated RPM: | 2400 |
| Torque: | 90 lb-ft 122.0 Nm |
| Torque RPM: | 1650 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| Wheelbase: | 78.4 inches 199 cm |
| Length: | 156.7 inches 398 cm |
| Width: | 65 inches 165 cm |
| Height (exhaust): | 84.7 inches 215 cm |
| Weight: | 4442 lbs 2014 kg |
| Ground clearance: | 12.8 inches 32 cm |
| Front tread: | 49.2 inches 124 cm |
| Rear tread: | 51.2 inches 130 cm |
