Challenger MT585B

Production: 2010 - 2012

Production
Manufacturer:	Challenger (a part of AGCO)
Type:	Row-Crop tractor

Challenger MT585B Power
Engine (gross):	200 hp 149.1 kW
PTO (claimed):	165 hp 123.0 kW
Drawbar (tested):	149.22 hp 111.3 kW
PTO (tested):	207.82 hp 155.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Cab:	Cab standard with air-conditioning.
Transmission:	continuously variable transmission

Capacity
Fuel:	94 gal 355.8 L
Hydraulic system:	26.4 gal 99.9 L

Hydraulics
Type:	closed center pressure flow compensated
Capacity:	26.4 gal 99.9 L
Pressure:	2900 psi 200.0 bar
Valves:	3 or 4
Total flow:	29 gpm 109.8 lpm
39 gpm 147.6 lpm (optional)

Tractor hitch
Rear Type:	III
Control:	lower link draft sensing
Rear lift (at 24"/610mm):	16140 lbs 7321 kg
Front Hitch:	optional
Front lift:	8800 lbs 3991 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540/540E/1000 (1.375)
Front PTO:	optional
Front RPM:	1000 (1.375)

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	175
Batteries:	2
Battery CCA:	600 (each)
Battery volts:	12

Engine Detail
AGCO SISU Power 74CTA
wastegate turbocharged and air-to-air intercooled diesel
6-cylinder 24-valve
liquid-cooled inline
Displacement:	449.4 ci 7.4 L
Bore/Stroke:	4.252x5.276 inches 108 x 134 mm
Emissions:	Tier III
Power (gross):	200 hp 149.1 kW
Maximum Power:	225 hp 167.8 kW
Fuel system:	electronic common rail
Rated RPM:	2200
Starter:	electric
Starter volts:	12
Coolant capacity:	35.9 qts 34.0 L

Transmission
Transmission:	Techstar CVT
Type:	continuously variable transmission
Gears:	infinite forward and reverse
Oil capacity:	55 qts 52.1 L

Dimensions
Wheelbase:	118 inches 299 cm
Length:	199.5 inches 506 cm
Width:	118.1 inches 299 cm (min)
Height (cab):	121.9 inches 309 cm
Shiping weight:	16400 lbs 7439 kg
Clearance (drawbar):	16 inches 40 cm
Rear axle:	88 inch length 2235 mm
Rear axle:	120 inch length 3048 mm
Rear tread:	60 to 88 inches 152 to 223 cm
Rear tread:	60 to 120 inches 152 to 304 cm (long bar)
