Challenger MT515D
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Challenger (a part of AGCO) |
| Type: | Row-Crop tractor |
| Factory: | Beauvais, France |
| Original price: | $124,777 (2013 ) |
Challenger MT515D Power | |
| Engine: | 120 hp 89.5 kW |
| PTO (claimed): | 110 hp 82.0 kW |
| Drawbar (tested): | 100.6 hp 75.0 kW |
| PTO (tested): | 135.6 hp 101.1 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Cab standard with air-conditioning. AGCO System 150*Optional |
| AGCOMMAND*Optional | |
| Transmission: | 16-speed four-speed power shift |
Hydraulics | |
| Type: | closed center load sensing (CCLS) |
| Pressure: | 2900 psi 200.0 bar |
| Valves: | 2 to 4 |
| Total flow: | 29 gpm 109.8 lpm |
Tractor hitch | |
| Rear Type: | III/II |
| Control: | electronic lower link draft control |
| Drawbar: | Cat. 2 |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| 540/540E/1000 | |
| 540E/1000E/1000/1000E | |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 175 |
| 240*Total capacity with dual 120A alternator option. | |
| Batteries: | 2 |
| Battery CCA: | 600 |
| Battery volts: | 12 |
Engine Detail | |
AGCO Power | |
| turbocharged intercooled diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 402.5 ci 6.6 L |
| Bore/Stroke: | 4.252x4.724 inches 108 x 120 mm |
| Emissions: | Interim Tier IV |
| Emission control: | selective catalyitic reduction (SCR) |
| Power: | 120 hp 89.5 kW |
| Fuel system: | electronic high pressure common rail |
| Air cleaner: | dual stage dry |
| Starter: | electric |
| Starter volts: | 12 |
Transmission | |
| Transmission: | AutoPower IV |
| Type: | four-speed power shift |
| Gears: | 16 forward and reverse |
Dimensions | |
| Rear axle: | Flange |
| Rear axle: | Bar: 3.23 by 80 inches 82 by 2032 mm |
| Rear axle: | Long bar: 3.23 by 105 inches 82 by 2667 mm |
