Century 2028

Production: 2002 - 2004

Production
Distributor:	Century
Manufacturer:	Kukje
Type:	Compact Utility tractor
Factory:	Yangsu-ri, South Korea

Century 2028 Power
Engine (gross):	30 hp 22.4 kW
Engine (net):	28 hp 20.9 kW
PTO (claimed):	25 hp 18.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS.
Transmission:	12-speed partially synchronized

Hydraulics
Type:	open center
Valves:	1 or 2
Pump flow:	8.9 gpm 33.7 lpm
Total flow:	11.4 gpm 43.1 lpm
Steering flow:	2.5 gpm 9.5 lpm

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift (at ends):	2580 lbs 1170 kg

Power Take-off (PTO)
Rear PTO:	live*Two-stage foot clutch.
Clutch:	mechanical dry disc
Rear RPM:	540

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	45
Battery volts:	12

Engine Detail
Kukje
diesel
3-cylinder
liquid-cooled
Displacement:	95 ci 1.6 L
Power (gross):	30 hp 22.4 kW
Fuel system:	indirect injection
Pre-heating:	glow plugs
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Type:	partially synchronized
Gears:	12 forward and reverse
Clutch:	mechanical dry disc
Oil capacity:	37 qts 35.0 L
Oil type:	10oF [-12oC]↑	: JDM J20C
70o↔-40oF [21o↔-40oC]	: JDM J20D

Dimensions
Wheelbase:	65 inches 165 cm
Length:	120 inches 304 cm
Width:	59 inches 149 cm
Height (ROPS):	94 inches 238 cm
Shiping weight:	3640 lbs 1651 kg
Ground clearance:	11 inches 27 cm
