Case IH Farmall 30B

Production: 2012 - 2014

Production
Manufacturer:	Case IH
Type:	Compact Utility tractor
Original price:	$16,113 (2012 shuttle )
Original price:	$17,712 (2012 hydro )

Case IH Farmall 30B Power
Engine (gross):	28 hp 20.9 kW
Gear PTO (claimed):	23 hp 17.2 kW
Hydro PTO (claimed):	22 hp 16.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	Two-post foldable ROPS.
Transmissions:	12-speed partially synchronized
hydrostatic

Hydraulics
Type:	open center
Pressure:	open psi 0.0 bar center
Pump flow:	8.2 gpm 31.0 lpm
Steering flow:	4.1 gpm 15.5 lpm

Tractor hitch
Rear Type:	1
Control:	position control
Rear lift (at ends):	1,807 lbs 819 kg
Rear lift (at 24"/610mm):	1,433 lbs 650 kg
Drawbar:	two-position swinging drawbar

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	50
Battery CCA:	660
Battery volts:	12
Battery AH:	80

Engine Detail
Mitsubishi S4L
diesel
4-cylinder
liquid-cooled
Displacement:	92 ci 1.5 L
Power (gross):	28 hp 20.9 kW
Air cleaner:	dry
Pre-heating:	glow plugs
Rated RPM:	2600

Dimensions
Wheelbase:	66 inches 167 cm
Length:	119 inches 302 cm
Height (ROPS):	91 inches 231 cm
Weight:	3,121 lbs 1415 kg
Rear axle:	Flange
Front tread:	45.6 inches 115 cm
