Case IH D33

Production: 2001 - 2003

Contents:

Production

Manufacturer:Case IH

Variants

gear
hydrostatic

Case IH D33 Power

Engine (gross):33 hp 24.6 kW
PTO (claimed):28.6 hp 21.3 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD (optional)
Cab:Two-post ROPS. Foldable ROPS optional.
Transmission:9-speed gear

Hydraulics

Total flow:6.6 gpm 25.0 lpm

Tractor hitch

Rear Type:I
Rear lift (at 24"/610mm):1,635 lbs 741 kg

Power Take-off (PTO)

Rear PTO:transmission
Rear RPM:540
Mid PTO:optional
Mid RPM:2000

Electrical

Charging system:alternator
Charging amps:40
Battery CCA:420
Battery volts:12

Engine Detail

Shibaura
diesel
3-cylinder
liquid-cooled
Displacement:91.3 ci 1.5 L
Power (gross):33 hp 24.6 kW
Air cleaner:dual element
Pre-heating:glow plugs
Rated RPM:2800
Starter volts:12

Transmission

Type:gear
Gears:9 forward and 3 reverse
