Case IH 235
Type: Compact Utility Tractors
Contents:
Production | |
| Distributor: | Case IH |
| Manufacturer: | Mitsubishi |
| Type: | Compact Utility tractor |
| Original price: | $10,000 (1990 ) |
Case IH 235 Power | |
| Engine: | 18 hp 13.4 kW |
| PTO (claimed): | 15.2 hp 11.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Brakes: | mechanical drum |
| Cab: | Two-post folding ROPS. Optional canopy. |
| Transmissions: | 6-speed |
| hydrostatic | |
Capacity | |
| Fuel: | 4.8 gal 18.2 L |
| Hydraulic system: | 3.1 gal 11.7 L |
Hydraulics | |
| Capacity: | 3.1 gal 11.7 L |
| Valves: | 0 or 1 |
| Total flow: | 3.4 gpm 12.9 lpm |
Tractor hitch | |
| Rear Type: | I |
| Rear lift (at ends): | 1,035 lbs 469 kg |
| Rear lift (at 24"/610mm): | 816 lbs 370 kg |
Power Take-off (PTO) | |
| Gear Rear PTO: | transmission |
| Hydro Rear PTO: | live |
| Rear RPM: | 540 |
| Mid PTO: | live*Optional with hydrostatic |
| Mid RPM: | 2400 |
| Front RPM: | 2700*Optional |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 35 |
| Battery volts: | 12 |
Engine Detail | |
| Mitsubishi | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 51.8 ci 0.8 L |
| Bore/Stroke: | 2.68x3.07 inches 68 x 78 mm |
| Power: | 18 hp 13.4 kW |
| Air cleaner: | dry type cyclone |
| Rated RPM: | 2700 |
| Starter volts: | 12 |
| Oil capacity: | 3.2 qts 3.0 L |
| Coolant capacity: | 5.2 qts 4.9 L |
Dimensions | |
| Wheelbase: | 56 inches 142 cm |
| Length: | 102.5 inches 260 cm |
| 2WD Width: | 37 inches 93 cm |
| 4WD Width: | 39.2 inches 99 cm |
| Ground clearance: | 11.5 inches 29 cm (frame) |
| 2WD Clearance (front axle): | 11.0 inches 27 cm |
| 4WD Clearance (front axle): | 9.4 inches 23 cm |
| 2WD Front tread: | 28.3 inches 71 cm |
| 4WD Front tread: | 32.1 inches 81 cm |
| Rear tread: | 29.1 to 35 inches 73 to 88 cm |
