Case 810

Production: 1958 - 1964

Production
Manufacturer:	J.I. Case
Type:	Agricultural Crawler tractor
Factory:	Churubusco, Indiana, USA

Variants

industrial crawler

ag crawler

J.I. Case 810 Power
Engine (gross):	80 hp 59.7 kW
Plows:	5
Drawbar (tested):	38.57 hp 28.8 kW

Mechanical
Chassis:	crawler
Brakes:	hydraulic disc
Cab:	Open operator station.
Transmission:	4-speed power shift

Hydraulics
Pump flow:	30 gpm 113.6 lpm

810 Serial Numbers
1957:	7080001
1958:	7080541
1959:	7080999

Engine Detail
Continental HD-277
diesel
4-cylinder
liquid-cooled
Displacement:	277 ci 4.5 L
Bore/Stroke:	4.00x5.50 inches 102 x 140 mm
Power (gross):	80 hp 59.7 kW
Air cleaner:	oil bath
Compression:	15:1
Rated RPM:	2250
Torque:	204 lb-ft 276.6 Nm
Torque RPM:	1200
Starter:	electric
Starter volts:	24

Transmission
Transmission:	Terramatic
Type:	power shift
Gears:	4 forward and reverse
Clutch:	hydraulic disc

Dimensions
Wheelbase:	73 inches 185 cm
Length:	139.8 inches 355 cm
Width:	69 inches 175 cm
Height (steering wheel):	71.5 inches 181 cm
Operating weight:	15000 lbs 6804 kg
Gauge:	54 inches 137 cm
