Case 800-B
Type: Standard-tread Tractors
Contents:
Production | |
| Manufacturer: | J.I. Case |
| Type: | Standard-tread tractor |
| Factory: | Racine, Wisconsin, USA |
| Total built: | 255 |
Variants | |
| diesel standard | |
| diesel row-crop | |
| diesel Western special | |
| diesel high-crop | |
| gas standard | |
| gas row-crop | |
| gas Western special | |
| gas high-crop |
J.I. Case 800-B Power | |
| Belt (claimed): | 54 hp 40.3 kW |
| Plows: | 5 |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power |
| Brakes: | mechanical disc |
| Cab: | Open operator station. |
| Transmission: | 8-speed torque converter |
Tractor hitch | |
| Type: | Case Eagle Hitch (optional) |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
Engine Detail | |
| J.I. Case | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 267 ci 4.4 L |
| Bore/Stroke: | 4.125x5.00 inches 105 x 127 mm |
| Air cleaner: | oil bath |
| Compression: | 15:1 |
| Rated RPM: | 1800 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 9 qts 8.5 L |
| Coolant capacity: | 30 qts 28.4 L |
Transmission | |
| Transmission: | Case-O-Matic |
| Type: | torque converter |
| Gears: | 8 forward and 2 reverse |
| Clutch: | hydraulic wet disc |
| Four gears, plus reservse, in two ranges controlled with a single shift lever. Torque converter transmission with bypass to lock in direct drive. | |
Dimensions | |
| Wheelbase: | 82.75 inches 210 cm |
| Length: | 133.75 inches 339 cm |
| Height: | 66.375 inches 168 cm |
| Height (hood): | 61.375 inches 155 cm |
| Front tread: | 52/58 inches 132/147 cm |
| Rear tread: | 52/56/60/64 inches 132/142/152/162 cm |
