Bolens G244
Type: Compact Utility Tractors
Contents:
Production | |
| Distributor: | Bolens |
| Manufacturer: | Iseki |
| Type: | Compact Utility tractor |
Variants | |
| 2WD | |
| 4WD |
Bolens G244 Power | |
| Engine: | 24 hp 17.9 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | mechanical standard |
| Steering: | manual |
| Brakes: | mechanical shoe |
| Cab: | Open operator station. Two-post ROPS (#1960) optional with available canopy. Soft-side cab (#19706) optional |
| Transmission: | 18-speed gear |
Hydraulics | |
| Type: | open center |
| Pressure: | 2000 psi 137.9 bar |
| Pump flow: | 3.1 gpm 11.7 lpm |
Tractor hitch | |
| Rear Type: | 1 |
| Control: | Position control |
Power Take-off (PTO) | |
| Rear PTO: | transmission |
| Rear RPM: | 540/1000 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Isuzu 2AB1 | |
| diesel | |
| 2-cylinder | |
| liquid-cooled | |
| Displacement: | 72.2 ci 1.2 L |
| Power: | 24 hp 17.9 kW |
| Pre-heating: | glow plugs |
| Rated RPM: | 2600 |
| Torque: | 50 lb-ft 67.8 Nm |
| Torque RPM: | 2000 |
| Starter: | electric |
| Starter volts: | 12 |
Transmission | |
| Type: | gear |
| Gears: | 18 forward and 6 reverse |
| Clutch: | dry disc |
| Three gears (1-3), plus reverse (R) in three ranges (L/M/H) with additional two-range shift. | |
Dimensions | |
| Wheelbase: | 54.1 inches 137 cm |
| Length: | 105.5 inches 267 cm |
| Width: | 49 inches 124 cm |
| Height: | 76.8 inches 195 cm |
| Weight: | 1,903 lbs 863 kg |
| Ground clearance: | 10.2 inches 25 cm |
| Front tread: | 37.4 inches 94 cm |
| Rear tread: | 38 to 48 inches 96 to 121 cm |
