Benye 804

Production
Manufacturer:	Benye
Factory:	Ningbo, Zhejiang, China

Benye 804 Power
Engine:	80 hp 59.7 kW

Mechanical
Steering:	hydrostatic power
Brakes:	wet disc
Transmission:	8-speed

Capacity
Fuel:	28.5 gal 107.9 L
Hydraulic system:	9.9 gal 37.5 L

Hydraulics
Capacity:	9.9 gal 37.5 L
Pressure:	2466 psi 170.0 bar
Valves:	1
Total flow:	11.1 gpm 42.0 lpm

Tractor hitch
Rear Type:	II
Rear lift:	5,622 lbs 2550 kg

Power Take-off (PTO)
Rear PTO:	live
Rear RPM:	540/1000

Electrical
Charging amps:	36
Battery volts:	12

Engine Detail
LRC4108T69
diesel
4-cylinder
liquid-cooled
Displacement:	274.6 ci 4.5 L
Power:	80 hp 59.7 kW
Air cleaner:	dual dry element
Rated RPM:	2300

Transmission
Gears:	8 forward and 2 reverse

Dimensions
Wheelbase:	90.6 inches 230 cm
Length:	170.3 inches 432 cm
Width:	79.9 inches 202 cm
Height:	108.7 inches 276 cm
Weight:	6,505 lbs 2950 kg
Ground clearance:	15.4 inches 39 cm
