Belarus 7011

Production: 1975 - 2002

Production
Manufacturer:	Belarus
Type:	Four-wheel Drive (4WD) tractor
Factory:	Saint Petersburg, Russia

Belarus 7011 Power
Engine:	225 hp 167.8 kW
PTO (claimed):	215 hp 160.3 kW

Mechanical
Chassis:	4x4 articulated 4WD
Steering:	articulated power
Brakes:	pneumatic drum
Cab:	Cab standard.
Transmission:	16-speed four-speed power shift

Capacity
Fuel:	169.1 gal 640.0 L
Hydraulic system:	33.3 gal 126.0 L

Hydraulics
Type:	open center
Capacity:	33.3 gal 126.0 L
Valves:	2
Pump flow:	17.8 gpm 67.4 lpm

Tractor hitch
Rear Type:	IV

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	1000

Electrical
Charging system:	alternator

Engine Detail
YaMZ 238 ND
turbocharged diesel
8-cylinder
liquid-cooled V-8
Displacement:	906.8 ci 14.9 L
Bore/Stroke:	5.12x5.51 inches 130 x 140 mm
Power:	225 hp 167.8 kW
Fuel system:	direct injection
Air cleaner:	dry
Rated RPM:	1700
Torque:	687 lb-ft 931.6 Nm
Torque RPM:	1100
Firing order:	1-5-4-2-6-3-7-8
Starter type:	electric
Oil capacity:	33.8 qts 32.0 L

Transmission
Type:	four-speed power shift
Gears:	16 forward and 8 reverse
Oil capacity:	24.3 qts 23.0 L
Four power shift gears in four ranges.

Dimensions
Wheelbase:	126:126 inches 320 cm
Length:	291.3 inches 739 cm
Width:	113.4 inches 288 cm
Height:	139.8 inches 355 cm
Shiping weight:	26010 lbs 11798 kg
Operating weight:	28240 lbs 12809 kg
Front tread:	83.3 inches 211 cm
Rear tread:	83.3 inches 211 cm
