AGCO GT55

Production: 2004 - 2007

Production
Manufacturer:	AGCO
Type:	Utility tractor
Factory:	Italy

AGCO GT55 Power
Engine:	56 hp 41.8 kW
PTO (claimed):	53 hp 39.5 kW
PTO (tested):	58.89 hp 43.9 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS. Cab optional with air-conditioning.
Transmission:	16-speed

Hydraulics
Type:	open center
Pump flow:	14 gpm 53.0 lpm
Total flow:	22.7 gpm 85.9 lpm

Tractor hitch
Rear Type:	II
Rear lift (at 24"/610mm):	3520 lbs 1596 kg
Rear Arms:	fixed
telescopic*Optional

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540/1000
Engine RPM:	540@1967 1000@2043

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
SAME Deutz-Fahr
turbocharged diesel
3-cylinder
liquid-cooled
Displacement:	183 ci 3.0 L
Bore/Stroke:	4.134x4.547 inches 105 x 115 mm
Power:	56 hp 41.8 kW
Air cleaner:	dry element
Compression:	16:1
Rated RPM:	2200
Torque:	185 lb-ft 250.9 Nm
Torque RPM:	1349
Starter volts:	12

Transmission
Transmission:	synchro-shuttle
Gears:	16 forward and 8 reverse
Clutch:	dry disc

Dimensions
2WD Wheelbase:	82.9 inches 210 cm
4WD Wheelbase:	80.9 inches 205 cm
Length:	145.7 inches 370 cm
Width:	70.4 inches 178 cm
Height:	104.6 inches 265 cm
2WD Front tread:	54.6 to 66.4 inches 138 to 168 cm
4WD Front tread:	57.5 to 69.1 inches 146 to 175 cm
Rear tread:	55.1 to 74.8 inches 139 to 189 cm
