Kubota L4600

Production: 2011 - 2014

PDF

• Download Kubota L4600 Operator's Manual

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Variants
L4600F:	2WD Gear
L4600DT:	4WD Gear
L4600HST:	4WD Hydro

Kubota L4600 Power
Engine (gross):	46.3 hp 34.5 kW
Engine (net):	43.8 hp 32.7 kW
Hydro PTO (claimed):	36.8 hp 27.4 kW
Gear PTO (claimed):	38.3 hp 28.6 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	rear standard
Steering:	hydrostatic power
Brakes:	mechanical wet disc
Cab:	Two-post foldable ROPS.
Transmission:	8-speed synchronized shuttle

Hydraulics
Type:	open center gear pump
Valves:	0 to 3
Pump flow:	8.4 gpm 31.8 lpm
Total flow:	13.5 gpm 51.1 lpm
Steering flow:	5.1 gpm 19.3 lpm

Tractor hitch
Rear Type:	1
Control:	position control
Rear lift (at ends):	2,870 lbs 1301 kg
Rear lift (at 24"/610mm):	2,320 lbs 1052 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic wet disc
Rear RPM:	540 (1.375)
Engine RPM:	540@2475

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	40
Charging volts:	12
Battery CCA:	582
Battery volts:	12

Engine Detail
Kubota E-TVCS
diesel
4-cylinder
liquid-cooled
Displacement:	134.1 ci 2.2 L
Bore/Stroke:	3.4x3.6 inches 86 x 91 mm
Emissions:	Intertim Tier 4
Power (gross):	46.3 hp 34.5 kW
Fuel system:	indirect injection
Rated RPM:	2600
Starter volts:	12
Oil capacity:	8 qts 7.6 L
Coolant capacity:	6.9 qts 6.5 L

Transmission
Type:	synchronized shuttle
Gears:	8 forward and reverse
Clutch:	dry disc
Oil capacity:	42.4 qts 40.1 L

Dimensions
2WD Wheelbase:	72.8 inches 184 cm
4WD Wheelbase:	72.6 inches 184 cm
2WD Length:	122.8 inches 311 cm
4WD Length:	117.9 inches 299 cm
Width:	62.4 inches 158 cm
Height:	91.7 inches 232 cm
Ground clearance:	15.2 inches 38 cm
Front tread:	50.4/54.3/58.3/62.2 inches 128/137/148/157 cm(2WD)
Front tread:	45.5 inches 115 cm (4WD)
Rear tread:	46.5/47.2/51.2/57.1/60.8 inches 118/119/130/145/154 cm
