Kioti CS2610

Production: 2013

PDF

• Download Kioti CS2610 Manual

Production
Manufacturer:	Kioti (a part of Daedong)
Type:	Sub-Compact Utility tractor
Factory:	South Korea

Kioti CS2610 Power
Engine (gross):	26 hp 19.4 kW
Engine (net):	24 hp 17.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS.
Transmission:	hydrostatic

Hydraulics
Type:	open center
Pump flow:	6.5 gpm 24.6 lpm

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift (at 24"/610mm):	700 lbs 317 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
Mid RPM:	2200

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Shibaura S773L
diesel
3-cylinder
liquid-cooled
Displacement:	69 ci 1.1 L
Bore/Stroke:	3.03x3.19 inches 77 x 81 mm
Power (gross):	26 hp 19.4 kW
Rated RPM:	3000
Starter:	electric
Starter volts:	12

Transmission
Type:	hydrostatic
Gears:	infinite (2-range) forward and reverse

Dimensions
Wheelbase:	55.1 inches 139 cm
Length:	98.1 inches 249 cm
Width:	46.5 inches 118 cm
Height (ROPS):	88 inches 223 cm
Weight:	1485 lbs 673 kg
Ground clearance:	6.4 inches 16 cm
Front tread:	45.8 inches 116 cm
Rear tread:	50 inches 127 cm
