Zetor Proxima Power 85

Production: 2009 - 2010

Production
Manufacturer:	Zetor
Type:	Utility tractor
Factory:	Brno, Czech Republic

Zetor Proxima Power 85 Power
Engine (net):	82 hp 61.1 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	electro-pneumatic
Steering:	power
Brakes:	hydraulic wet disc
Trailer brakes:	pneumatic
hydraulic*Optional
Cab:	Cab standard with optional air-conditioning.
Transmission:	24-speed three-speed power shift

Hydraulics
Pressure:	2611 psi 180.0 bar
Valves:	3
Total flow:	13.2 gpm 50.0 lpm

Tractor hitch
Rear Type:	II/I
Control:	position control and mechanical top-link draft sensing
Rear lift:	9330 lbs 4232 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	wet disc
Rear RPM:	540/1000
540/540E
Front RPM:	1000

Electrical
Charging system:	alternator

Engine Detail
Zetor 1205
turbocharged diesel
4-cylinder 8-valve
liquid-cooled
Displacement:	253.6 ci 4.2 L
Bore/Stroke:	4.13x4.72 inches 105 x 120 mm
Emissions:	Stage III
Rated Power (ECE R24):	82 hp 61.1 kW
Rated RPM:	2200
Starter type:	electric

Transmission
Type:	three-speed power shift
Gears:	24 forward and reverse
Clutch:	electro-hydraulic wet disc

Dimensions
Wheelbase:	91.7 inches 232 cm
Length:	153.7 inches 390 cm
Width:	75.2 inches 191 cm
Height:	107 inches 271 cm
Weight:	8818 lbs 3999 kg
Ground clearance:	16.5 inches 41 cm
