Zetor 6011

Production: 1980 - 1984

Production
Manufacturer:	Zetor
Type:	Utility tractor
Factory:	Brno, Czechoslovakia

Variants

2WD

4WD

Zetor 6011 Power
Engine:	60 hp 44.7 kW

Mechanical
Chassis:	4x2 2WD
Steering:	power assist
Brakes:	drum
Cab:	Cab standard.
Transmission:	10-speed partially-synchronized

Hydraulics
Pressure:	2321 psi 160.0 bar
Pump flow:	5.3 gpm 20.1 lpm

Tractor hitch
Rear Type:	II
Rear lift:	3748 lbs 1700 kg

Power Take-off (PTO)
Rear PTO:	live
Rear RPM:	540/1000

Engine Detail
Zetor Z6001
diesel
4-cylinder
liquid-cooled
Displacement:	210.9 ci 3.5 L
Bore/Stroke:	3.937x4.331 inches 100 x 110 mm
Power:	60 hp 44.7 kW
Rated RPM:	2200
Torque:	132 lb-ft 179.0 Nm
Torque RPM:	1600
Starter:	electric
Starter volts:	12

Transmission
Type:	partially-synchronized
Gears:	10 forward and 2 reverse
Five gears (1-5) in two ranges (low-high). Synchronized shifting between gears 4 and 5.

Dimensions
Wheelbase:	88.6 inches 225 cm
Length:	144.1 inches 366 cm
Height (cab):	96.5 inches 245 cm
Weight:	6658 lbs 3020 kg
