Zetor 4011
Contents:
Production | |
| Manufacturer: | Zetor |
| Factory: | Brno, Czechoslovakia |
Zetor 4011 Power | |
| Engine: | 53 hp 39.5 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Cab: | Open operator station. |
| Transmission: | 10-speed gear |
Hydraulics | |
| Valves: | 1 |
| Pump flow: | 5.3 gpm 20.1 lpm |
Tractor hitch | |
| Rear Type: | II |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
Engine Detail | |
| Zetor | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 190.3 ci 3.1 L |
| Bore/Stroke: | 3.74x4.331 inches 95 x 110 mm |
| Power: | 53 hp 39.5 kW |
| Rated RPM: | 2000 |
| Starter volts: | 12 |
| Oil capacity: | 11.6 qts 11.0 L |
| Coolant capacity: | 13.7 qts 13.0 L |
Transmission | |
| Type: | gear |
| Gears: | 10 forward and 2 reverse |
| Clutch: | dry disc |
| Five gears, plus reverse, in two ranges. | |
Dimensions | |
| Wheelbase: | 83.4 inches 211 cm |
| Length: | 128 inches 325 cm |
| Width: | 70.5 inches 179 cm |
| Height (steering wheel): | 63.8 inches 162 cm |
| Weight: | 4332 lbs 1964 kg |
| Ballasted weight: | 6647 lbs 3015 kg |
| Front tread: | 53.1 to 68.9 inches 134 to 175 cm |
| Rear tread: | 56.1 to 70.9 inches 142 to 180 cm |
