Zetor 12011

Production: 1974 - 1987

Production
Manufacturer:	Zetor
Type:	Row-Crop tractor
Factory:	Brno, Czechoslovakia

Variants

2WD

4WD

Zetor 12011 Power
Engine:	120 hp 89.5 kW

Mechanical
Chassis:	4x2 2WD
Brakes:	hydraulic dry disc
Cab:	Cab standard.
Transmission:	16-speed

Hydraulics
Type:	open center
Valves:	1
Pump flow:	8.4 gpm 31.8 lpm

Tractor hitch
Rear Type:	II
Control:	lower-link draft control
Rear lift:	7496 lbs 3400 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Engine Detail
Zetor Z 8601
diesel
6-cylinder
liquid-cooled
Displacement:	417.5 ci 6.8 L
Bore/Stroke:	4.331x4.724 inches 110 x 120 mm
Power:	120 hp 89.5 kW
Fuel system:	direct injection
Rated RPM:	2200

Transmission
Transmission:	synchro mesh
Gears:	16 forward and 8 reverse
Four gears in two ranges with two-speed torque multiplier.

Dimensions
Length:	167.5 inches 425 cm
Width:	77.4 inches 196 cm
Height (cab):	98.8 inches 250 cm
Weight:	9039 lbs 4100 kg
Ballasted weight:	10820 lbs 4907 kg
Ground clearance:	17.5 inches 44 cm
Front tread:	53.2 to 70.9 inches 135 to 180 cm
