Yanmar YM186
Type: Compact Utility Tractors
Contents:
Production | |
| Manufacturer: | Yanmar |
| Type: | Compact Utility tractor |
| Original price: | $7,400 (1986 ) |
Variants | |
| YM186: | 2WD |
| YM186D: | 4WD |
Yanmar YM186 Power | |
| Engine (gross): | 18 hp 13.4 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | manual |
| power optional | |
| Brakes: | mechanical dry shoe |
| Cab: | Open operator station. ROPS optional. |
| Transmission: | 9-speed |
Capacity | |
| Fuel: | 4.2 gal 15.9 L |
| Hydraulic system: | 2.1 gal 7.9 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 2.1 gal 7.9 L |
| Pressure: | 1991 psi 137.3 bar |
| Total flow: | 4.8 gpm 18.2 lpm |
Tractor hitch | |
| Rear Type: | I |
| Rear lift (at 24"/610mm): | 551 lbs 249 kg |
Power Take-off (PTO) | |
| Rear PTO: | transmission |
| Rear RPM: | 540/1000 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 15 |
| Battery volts: | 12 |
| Battery AH: | 45 |
Engine Detail | |
| Yanmar 3T72HA | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 53.5 ci 0.9 L |
| Bore/Stroke: | 2.83x2.83 inches 72 x 72 mm |
| Power (gross): | 18 hp 13.4 kW |
| Compression: | 23:1 |
| Rated RPM: | 2600 |
| Firing order: | 1-3-2 |
| Starter volts: | 12 |
| Oil capacity: | 3.4 qts 3.2 L |
| Coolant capacity: | 4.4 qts 4.2 L |
| Intake valve clearance: | 0.008 inches 0.203 mm |
| Exhaust valve clearance: | 0.008 inches 0.203 mm |
Transmission | |
| Gears: | 9 forward and 3 reverse |
| Oil capacity: | 8.4 qts 7.9 L |
| Three speeds, plus reverse, with three ranges. | |
Dimensions | |
| Length: | 98.3 inches 249 cm |
| Width: | 42.9 inches 108 cm |
| Height (steering wheel): | 53.1 inches 134 cm |
| Height (exhaust): | 50.0 inches 127 cm |
| 2WD Shiping weight: | 1433 lbs 650 kg |
| 4WD Shiping weight: | 1539 lbs 698 kg |
| Ground clearance: | 10.4 inches 26 cm |
