Yanmar F-230

Production: 1992 - 1998

Production
Manufacturer:	Yanmar
Type:	Compact Utility tractor

Yanmar F-230 Power
Engine:	22.7 hp 16.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Cab:	Two-post ROPS. Cab optional.
Transmission:	12-speed shuttle

Tractor hitch
Rear Type:	JIS0

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	553@2500 727@2500 1210@2500 -667@2500

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	20

Engine Detail
Yanmar 3TNE82A
diesel
3-cylinder
liquid-cooled
Displacement:	81.2 ci 1.3 L
Bore/Stroke:	3.23x3.31 inches 82 x 84 mm
Power:	22.7 hp 16.9 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Transmission
Type:	shuttle
Gears:	12 forward and reverse
Four gears, in three ranges with left-hand shuttle shift.

Dimensions
Wheelbase:	55.9 inches 141 cm
Length:	105.9 inches 268 cm
Width:	47.6 inches 120 cm
Height (ROPS):	75.8 inches 192 cm
Height (cab):	76.6 inches 194 cm
ROPS Weight:	1940 lbs 879 kg
Cab Weight:	2083 lbs 944 kg
Ground clearance:	13.2 inches 33 cm
Front tread:	36.2 inches 91 cm
Rear tread:	37/41.7 inches 93/105 cm
