Versatile 2270
Contents:
Production | |
| Manufacturer: | Versatile (a part of Buhler) |
| Type: | Four-wheel Drive (4WD) tractor |
| Factory: | Winnipeg, Manitoba, Canada |
Versatile 2270 Power | |
| Engine: | 270 hp 201.3 kW |
Mechanical | |
| Chassis: | 4x4 articulated 4WD |
| Final drives: | outboard planetary |
| Steering: | articulated power |
| Cab: | Cab standard with air-conditioning. |
| Transmissions: | 12-speed partially synchronized |
| 12-speed full power shift | |
Hydraulics | |
| Type: | closed center load sensing |
| Pressure: | 2900 psi 200.0 bar |
| Valves: | 4 |
| Pump flow: | 45 gpm 170.3 lpm |
Tractor hitch | |
| Rear Type: | IVN/III |
| Rear lift: | 13000 lbs 5896 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent*Optional |
| Clutch: | electro-hydraulic wet disc |
| Rear RPM: | 1000 (1.75) |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 130 |
| Charging volts: | 12 |
| Batteries: | 3 |
| Battery CCA: | 625 |
| Battery volts: | 12 |
Engine Detail | |
| Cummins M11 | |
| turbocharged diesel | |
| 6-cylinder | |
| liquid-cooled inline | |
| Displacement: | 660 ci 10.8 L |
| Bore/Stroke: | 4.92x5.79 inches 125 x 147 mm |
| Power: | 270 hp 201.3 kW |
| Compression: | 16.1:1 |
| Rated RPM: | 2100 |
| Starter: | electric |
| Starter volts: | 12 |
