TAFE 3840

Production
Manufacturer:	TAFE
Factory:	India

TAFE 3840 Power
Engine:	38 hp 28.3 kW

Mechanical
Steering:	hydrostatic power
Brakes:	drum
Transmission:	8-speed

Hydraulics
Valves:	3
Total flow:	4.2 gpm 15.9 lpm

Tractor hitch
Rear lift:	2425.1 lbs 1100 kg

Power Take-off (PTO)
Rear RPM:	540

Electrical
Charging amps:	36
Battery volts:	12

Engine Detail
S325.3
diesel
3-cylinder
liquid-cooled
Displacement:	152.6 ci 2.5 L
Bore/Stroke:	3.598x5.00 inches 91 x 127 mm
Power:	38 hp 28.3 kW
Air cleaner:	dry
Rated RPM:	2000
Torque:	112.1 lb-ft 152.0 Nm
Torque RPM:	1200
Oil capacity:	6 qts 5.7 L
Coolant capacity:	10.4 qts 9.8 L

Transmission
Transmission:	sliding mesh
Gears:	8 forward and 2 reverse

Dimensions
Wheelbase:	77 inches 195 cm
Length:	126 inches 320 cm
Width:	63.8 inches 162 cm
Height:	88.6 inches 225 cm
Weight:	3,858 lbs 1749 kg
Ground clearance:	12.6 inches 32 cm
