Steyr 6170 CVT

Production: 2003 - 2007
Type: Utility Tractors

Contents:

Production

Manufacturer:Steyr
Type:Utility tractor

Steyr 6170 CVT Power

Engine:171 hp 127.5 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:STEYR luxury cab
Transmission:continuously variable transmission (CVT)

Hydraulics

Pressure:2973 psi 205.0 bar
Valves:5
Total flow:34.3 gpm 129.8 lpm

Tractor hitch

Rear Type:III/II
Rear lift:21,830 lbs 9902 kg
Front lift:8,822 lbs 4001 kg

Power Take-off (PTO)

Rear RPM:540/540E/1000/1000E
Front RPM:1000

Electrical

Ground:negative
Charging system:alternator

Engine Detail

Sisu
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:402.8 ci 6.6 L
Bore/Stroke:4.25x4.72 inches 108 x 120 mm
Power:171 hp 127.5 kW
Rated RPM:2100
Torque:535 lb-ft 725.5 Nm
Torque RPM:1400
Starter:electric
Starter volts:12

Transmission

Type:continuously variable transmission (CVT)
Gears:infinite forward and reverse

Dimensions

Wheelbase:111.5 inches 283 cm
Length:187.6 inches 476 cm
Width:98 inches 248 cm
Height:118 inches 299 cm
Weight:14,930 lbs 6772 kg
