Steiger Bearcat IV KM-225

Production: 1983 - 1985

Production
Manufacturer:	Steiger
Type:	Four-wheel Drive (4WD) tractor
Factory:	Fargo, North Dakota, USA
Original price:	$77,000 (1985 )

Variants

Caterpillar engine

Cummins engine

Steiger Bearcat IV KM-225 Power
Engine:	225 hp 167.8 kW
Drawbar (claimed):	190 hp 141.7 kW

Mechanical
Chassis:	4x4 articulated 4WD
Final drives:	outboard planetary
Steering:	articulated power
Brakes:	hydraulic disc
Cab:	Steiger Safari Cab standard with air-conditioning.
Transmission:	20-speed constant mesh gear

Hydraulics
Type:	open center
Pressure:	2250 psi 155.1 bar
Valves:	3 to 5
Pump flow:	30 gpm 113.6 lpm

Tractor hitch
Rear Type:	III*Optional

Electrical
Charging system:	alternator
Charging amps:	90
Batteries:	3
Battery volts:	12

Engine Detail
Cummins LT-10-A
turbocharged diesel
6-cylinder
liquid-cooled inline
Displacement:	611 ci 10.0 L
Bore/Stroke:	4.95x5.35 inches 126 x 136 mm
Power:	225 hp 167.8 kW
Rated RPM:	2100
Operating RPM:	1700-2100
Torque:	732 lb-ft 992.6 Nm
Torque RPM:	1300
Starter volts:	12
Oil capacity:	36 qts 34.1 L
Coolant capacity:	64 qts 60.6 L

Transmission
Transmission:	Spicer SST1010
Type:	constant mesh gear
Gears:	20 forward and 4 reverse

Dimensions
Wheelbase:	129 inches 327 cm
Length:	253.6 inches 644 cm
Width:	96 inches 243 cm *Width over fenders
144.3 inches 366 cm *Width over 18.4x38 duals
Shiping weight:	24411 lbs 11072 kg
Max weight:	34000 lbs 15422 kg
