Steiger 9150

Production: 1986 - 1990

Production
Manufacturer:	Steiger
Type:	Four-wheel Drive (4WD) tractor
Factory:	Fargo, North Dakota, USA
Original price:	$95,000 (1990)

Steiger 9150 Power
Engine:	280 hp 208.8 kW
PTO (claimed):	245 hp 182.7 kW

Mechanical
Chassis:	4x4 articulated 4WD
Steering:	hydrostatic power
Cab:	Cab standard.
Transmission:	12-speed full power shift

Capacity
Fuel:	170 gal 643.5 L
Hydraulic system:	18 gal 68.1 L

Hydraulics
Type:	closed center
Capacity:	18 gal 68.1 L
Pressure:	2500 psi 172.4 bar
Valves:	3 to 4
Total flow:	27 gpm 102.2 lpm

Tractor hitch
Optional Rear Type:	III
Rear lift:	12,750 lbs 5783 kg

Power Take-off (PTO)
Optional Rear PTO:	independent
Rear RPM:	1000

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Cummins LTA-10
turbocharged intercooled diesel
6-cylinder
liquid-cooled
Displacement:	611 ci 10.0 L
Bore/Stroke:	4.95x5.35 inches 126 x 136 mm
Power:	280 hp 208.8 kW
Rated RPM:	2100
Torque:	910 lb-ft 1234.0 Nm
Torque RPM:	1300
Starter volts:	12
Oil capacity:	33 qts 31.2 L
Coolant capacity:	60 qts 56.8 L

Transmission
Type:	full power shift
Gears:	12 forward and 2 reverse

Dimensions
Wheelbase:	130 inches 330 cm
Length:	272.9 inches 693 cm
Minimum Width:	119.5 inches 303 cm
Duals Width:	114.3 inches 290 cm
Height (exhaust):	143 inches 363 cm
Weight:	23,000 lbs 10432 kg
Frame Ground clearance:	23 inches 58 cm
