Schluter Super 1800TVL

Production: 1982 - 1986

Contents:

Production

Manufacturer:Schluter

Schluter Super 1800TVL Power

Engine:180 hp 134.2 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:drum
Cab:standard
Transmission:12-speed

Hydraulics

Total flow:13.5 gpm 51.1 lpm

Tractor hitch

Rear lift:13,671 lbs 6201 kg
18,522 lbs 8401 kg (optional)

Power Take-off (PTO)

Rear RPM:540/1000

Engine Detail

SDMT 112 W 6 LLK
intercooled turbo
6-cylinder
Displacement:450.9 ci 7.4 L
Bore/Stroke:4.409x4.921 inches 112 x 125 mm
Power:180 hp 134.2 kW
Rated RPM:2100
Torque:542.9 lb-ft 736.2 Nm
Torque RPM:1300

Transmission

Gears:12 forward and 6 reverse

Dimensions

Wheelbase:107.1 inches 272 cm
Length:183.9 inches 467 cm
Height:115.0 inches 292 cm
Weight:15,214 lbs 6901 kg
