Satoh Buck S470

Production: 1979 - 1984

Production
Manufacturer:	Satoh
Type:	Compact Utility tractor
Factory:	Japan

Variants
S470D:	4WD

Satoh S470 Power
Engine:	18.5 hp 13.8 kW
PTO (claimed):	15 hp 11.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD (S470D)
Steering:	manaul
Brakes:	drum
Cab:	Open operator station.
Transmission:	6-speed gear

Hydraulics
Pump flow:	3.5 gpm 13.2 lpm

Tractor hitch
Rear Type:	I
Control:	non-positional control
Rear lift (at ends):	1100 lbs 498 kg

Power Take-off (PTO)
Rear RPM:	540 (1.375)

Electrical
Ground:	negative
Battery volts:	12
Battery AH:	45

Engine Detail
Mitsubishi
diesel
3-cylinder
liquid-cooled
Displacement:	51.81 ci 0.8 L
Power:	18.5 hp 13.8 kW
Air cleaner:	dry
Compression:	23:1
Rated RPM:	2600
Starter volts:	12
Oil capacity:	3.1 qts 2.9 L
Coolant capacity:	5.3 qts 5.0 L

Transmission
Type:	gear
Gears:	6 forward and 2 reverse
Clutch:	dry disc
Oil capacity:	12.7 qts 12.0 L

Dimensions
Length:	75.3 inches 191 cm (2WD)
78.5 inches 199 cm (4WD)
Width:	36.9 inches 93 cm
Height:	47.2 inches 119 cm
Weight:	1157 lbs 524 kg (2WD)
1268 lbs 575 kg (4WD)
Ground clearance:	11.2 inches 28 cm (2WD)
9.3 inches 23 cm (4WD)
Front tread:	28.3 inches 71 cm (2WD)
Front tread:	30.9 inches 78 cm (4WD)
Rear tread:	30.3/33.9 inches 76/86 cm
