SAME Drago 120

Production: 1978 - 1986

Contents:

Production

Manufacturer:SAME

SAME Drago 120 Power

Engine:115 hp 85.8 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD optional
Transmission:12-speed

Power Take-off (PTO)

Rear RPM:540, 1000

Engine Detail

SAME
diesel
6-cylinder
Displacement:380.40 ci 6.2 L
Bore/Stroke:4.134x4.72 inches 105 x 120 mm
Power:115 hp 85.8 kW
Rated RPM:2070

Transmission

Gears:12 forward and 4 reverse

Dimensions

Wheelbase:104.72 inches 265 cm
Length:161.02 inches 408 cm
Height:109.45 inches 278 cm
Weight:9,150 lbs 4150 kg
10,076 lbs 4570 kg (4WD)
