Renault 90-34 MX

Production: 1989 - 1993

Contents:

Production

Manufacturer:Renault

Variants

2WD

Renault 90-34 MX Power

Engine:83 hp 61.9 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:standard
Transmission:12-speed

Hydraulics

Total flow:10.6 gpm 40.1 lpm

Tractor hitch

Rear lift:9,878 lbs 4480 kg

Power Take-off (PTO)

Rear RPM:540/1000

Engine Detail

MWM D226-4
diesel
4-cylinder
Displacement:253.6 ci 4.2 L
Bore/Stroke:4.134x4.724 inches 105 x 120 mm
Power:83 hp 61.9 kW
Rated RPM:2350
Torque:208.0 lb-ft 282.0 Nm
Torque RPM:1500

Transmission

Gears:12 forward and reverse

Dimensions

Wheelbase:94.1 inches 239 cm
Length:159.8 inches 405 cm
Height:98.4 inches 249 cm
Weight:8,577 lbs 3890 kg
