Renault 155-54

Production: 1989 - 2000

Production
Manufacturer:	Renault
Type:	Row-Crop tractor

Renault 155-54 Power
Engine:	145 hp 108.1 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with air conditioning.
Transmissions:	16-speed
24-speed

Hydraulics
Total flow:	19.6 gpm 74.2 lpm
21.4 gpm 81.0 lpm

Tractor hitch
Rear lift:	19,139 lbs 8681 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000 (1.375)

Engine Detail
MWM TD226-B6
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	380.4 ci 6.2 L
Bore/Stroke:	4.134x4.724 inches 105 x 120 mm
Power:	145 hp 108.1 kW
Compression:	16:1
Rated RPM:	2350
Torque:	400.5 lb-ft 543.1 Nm
Torque RPM:	1500

Dimensions
Wheelbase:	107.9 inches 274 cm
Length:	181.2 inches 460 cm
Height (cab):	117.4 inches 298 cm
Height (exhaust):	125.2 inches 318 cm
Weight:	12403 lbs 5626 kg
Front tread:	63.78.7 to inches 162 to 0 cm
Rear tread:	59.1 to 82.7 inches 150 to 210 cm
