Renault 1181

Production: 1976 - 1980

Contents:

Production

Manufacturer:Renault

Renault 1181 Power

Engine:118 hp 88.0 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:dry disc
Cab:standard
Transmission:12-speed

Hydraulics

Total flow:8.3 gpm 31.4 lpm

Tractor hitch

Rear lift:9,151 lbs 4150 kg

Power Take-off (PTO)

Rear RPM:540/1000

Engine Detail

MWM D226-6
diesel
6-cylinder
Displacement:380.4 ci 6.2 L
Bore/Stroke:4.134x4.724 inches 105 x 120 mm
Power:118 hp 88.0 kW
Rated RPM:2350
Torque:295.0 lb-ft 400.0 Nm
Torque RPM:1500

Transmission

Gears:12 forward and reverse

Dimensions

Wheelbase:105.5 inches 267 cm
Length:176.4 inches 448 cm
Height:107.9 inches 274 cm
Weight:10,364 lbs 4701 kg
