New Holland TG210

Production: 2003 - 2006

Production
Manufacturer:	New Holland
Type:	Row-Crop tractor
Factory:	Racine, Wisconsin, USA

New Holland TG210 Power
Engine:	210 hp 156.6 kW
PTO (claimed):	170 hp 126.8 kW
Drawbar (tested):	146.80 hp 109.5 kW
PTO (tested):	195.30 hp 145.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	hydraulic wet disc
Cab:	Cab standard with air-conditioning.
Transmissions:	18-speed full power shift
24-speed creeper

Hydraulics
Type:	closed center load sensing
Valves:	3 to 5
Pump flow:	38.6 gpm 146.1 lpm
68 gpm 257.4 lpm *With optional Mega Flow

Tractor hitch
Rear Type:	III/IIIN
Control:	position and electronic draft control
Rear lift (at 24"/610mm):	13520 lbs 6132 kg
15970 lbs 7243 kg *Optional

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	1000
540/1000*Optional

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	135
Batteries:	2
Battery CCA:	1000
Battery volts:	12
Battery Group:	31

Engine Detail
CDC
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	505 ci 8.3 L
Bore/Stroke:	4.488x5.315 inches 114 x 135 mm
Power:	210 hp 156.6 kW
Rated RPM:	2200
Idle RPM:	850-2505
Firing order:	1-5-3-6-2-4
Starter volts:	12
Intake valve clearance:	0.010 inches 0.254 mm *Cold
Exhaust valve clearance:	0.020 inches 0.508 mm *Cold

Dimensions
Operating weight:	20455 lbs 9278 kg
Ballasted weight:	23435 lbs 10630 kg
Front axle:	4WD
Front axle:	SuperSteer
Front axle:	TerraGlide
