New Holland T6050 Elite
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | New Holland |
| Type: | Row-Crop tractor |
| Factory: | Basildon, England |
Variants | |
| economy | |
| mid-level | |
| premium |
New Holland T6050 Elite Power | |
| Engine (gross): | 125 hp 93.2 kW |
| Engine (max): | 136 hp 101.4 kW |
| PTO (claimed): | 105 hp 78.3 kW |
| Drawbar (tested): | 90.9 hp 67.8 kW |
| PTO (tested): | 124.6 hp 92.9 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | hydrostatic power |
| Brakes: | hydraulic wet disc |
| Cab: | Horizon cab standard with air-conditioning. Optional deluxe cab with automatic temperature control and air-ride seat. Optional Comfort Ride cab suspension. Programmable headland management system. |
| Transmissions: | 16-speed partial power shift |
| 18-speed | |
Capacity | |
| Fuel: | 79.3 gal 300.2 L |
| Hydraulic system: | 18.5 gal 70.0 L |
Hydraulics | |
| Type: | closed center load sensing |
| Capacity: | 18.5 gal 70.0 L |
| Valves: | 2 to 4 |
| Pump flow: | 26.5 gpm 100.3 lpm |
| Total flow: | 43.6 gpm 165.0 lpm |
| Steering flow: | 17.1 gpm 64.7 lpm |
Tractor hitch | |
| Rear Type: | 2/3N |
| Control: | electronic lower-link draft control |
| Rear lift: | 12,185 lbs 5527 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 (1.375) |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 120 |
| Charging volts: | 12 |
| Battery CCA: | 1300 |
| Battery volts: | 12 |
Engine Detail | |
| FPT NEF | |
| turbocharged air-to-air intercooled diesel | |
| 6-cylinder 24-valve | |
| liquid-cooled | |
| Displacement: | 410.6 ci 6.7 L |
| Bore/Stroke: | 4.094x5.197 inches 104 x 132 mm |
| Emissions: | Tier 3 |
| Rated Power (ECE R120): | 125 hp 93.2 kW |
| Maximum Power (ECE R120): | 136 hp 101.4 kW |
| Fuel system: | high pressure common rail (HPCR) |
| Rated RPM: | 2200 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 16 qts 15.1 L |
Dimensions | |
| Wheelbase: | 104.4 inches 265 cm |
| 95.3 inches 242 cm (Terraglide axle) | |
| 99.2 inches 251 cm (SuperSteer axle) | |
| Height (cab): | 112.4 inches 285 cm |
| Height (exhaust): | 113.4 inches 288 cm |
| Shiping weight: | 11,836 lbs 5368 kg |
| Operating weight: | 13,260 lbs 6014 kg |
