New Holland T3020

Production: 2007

Production
Manufacturer:	New Holland

New Holland T3020 Power
Engine:	42.8 hp 31.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Cab:	optional with A/C
Transmission:	16-speed

Tractor hitch
Rear Type:	1
Rear lift (at ends):	2,646 lbs 1200 kg
Front Hitch:	1 optional
Front lift:	881.8 lbs 399 kg

Power Take-off (PTO)
Rear RPM:	540/540E
Front RPM:	1000 (optional)

Engine Detail
Yanmar
4-cylinder
liquid-cooled
Displacement:	121.7 ci 2.0 L
Power:	42.8 hp 31.9 kW
Rated RPM:	2800
Torque:	95 lb-ft 128.8 Nm
Torque RPM:	1400

Transmission
Transmission:	synchro shuttle
Gears:	16 forward and reverse

Dimensions
Wheelbase:	66.9 inches 169 cm
Length:	129.9 inches 329 cm
Width:	54.3 inches 137 cm
Height:	76 inches 193 cm (ROPS)
84.24 inches 213 cm (cab)
Weight:	3,219 lbs 1460 kg (ROPS)
3,549 lbs 1609 kg (cab)
