New Holland 1620

Production: 1996 - 1997

Production
Distributor:	New Holland
Manufacturer:	Shibaura
Type:	Compact Utility tractor
Factory:	Japan
Original price:	$17,000 (1997 )

New Holland 1620 Power
Engine (gross):	27.3 hp 20.4 kW
Engine (net):	26 hp 19.4 kW
PTO (claimed):	22 hp 16.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS.
Transmission:	hydrostatic

Hydraulics
Type:	open center
Pump flow:	7.1 gpm 26.9 lpm
Total flow:	10 gpm 37.9 lpm
Steering flow:	2.9 gpm 11.0 lpm

Tractor hitch
Rear Type:	I
Control:	draft control*Optional
Rear lift (at ends):	1934 lbs 877 kg
Rear lift (at 24"/610mm):	1637 lbs 742 kg

Power Take-off (PTO)
Rear PTO:	live
Rear RPM:	540
Mid RPM:	2000

1620 Serial Numbers
1992:	UJ20136
1993:	UJ20911
1994:	UJ21591
1995:	UJ22718
1996:	UJ23587

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Shibaura
diesel
3-cylinder
liquid-cooled
Displacement:	81.2 ci 1.3 L
Bore/Stroke:	3.307x3.15 inches 84 x 80 mm
Power (gross):	27.3 hp 20.4 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Type:	hydrostatic
Gears:	infinite forward and reverse

Dimensions
Wheelbase:	63 inches 160 cm
Length:	112.4 inches 285 cm
Width:	48.4 inches 122 cm
Height (ROPS):	84.3 inches 214 cm
2WD Shipping weight:	2233 lbs 1012 kg
4WD Shipping weight:	2352 lbs 1066 kg
2WD Ground clearance:	11.6 inches 29 cm
4WD Ground clearance:	11.2 inches 28 cm
2WD Front tread:	39.2 to 50 inches 99 to 127 cm
4WD Front tread:	42.4 inches 107 cm
2WD Rear tread:	39.3 to 53 inches 99 to 134 cm
4WD Rear tread:	41.1 to 47.1 inches 104 to 119 cm
