Montana R3644

Production: 2007 - 2010

Production
Distributor:	Montana
Manufacturer:	LS
Type:	Compact Utility tractor

Montana R3644 Power
Engine:	38.5 hp 28.7 kW
Gear PTO (claimed):	31 hp 23.1 kW
Hydro PTO (claimed):	29 hp 21.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS.
Transmissions:	12-speed
hydrostatic

Hydraulics
Pressure:	2417 psi 166.7 bar
Valves:	2
Pump flow:	8.1 gpm 30.7 lpm
Steering flow:	3.592 gpm 13.6 lpm
Steering press.:	1706 psi 117.6 bar

Tractor hitch
Rear Type:	I
Rear lift (at ends):	2619 lbs 1187 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540
Mid PTO:	optional

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	50
Battery volts:	12

Engine Detail
Mitsubishi S4L2
diesel
4-cylinder
liquid-cooled
Displacement:	107.3 ci 1.8 L
Bore/Stroke:	3.07x3.622 inches 78 x 92 mm
Power:	38.5 hp 28.7 kW
Fuel system:	indirect injection
Air cleaner:	dry dual element
Rated RPM:	2700
Starter volts:	12

Dimensions
Length:	117 inches 297 cm
Height:	91 inches 231 cm
Weight:	2712 lbs 1230 kg
Ground clearance:	13 inches 33 cm
