Mitsubishi GSK255

Production: 2013 - 2017

Production
Manufacturer:	Mitsubishi
Type:	Half-track Crawler tractor

Variants
GS251:	wheeled ROPS
GS251X:	wheeled cab
GSK255:	half-track

Mitsubishi GSK255 Power
Engine:	26.2 hp 19.5 kW

Mechanical
Chassis:	half-track
Steering:	power
Cab:	Two-post ROPS. Cab optional.
Transmission:	12-speed

Tractor hitch
Rear Type:	JIS0

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	523@2500 819@2500 1266@2500 -505@2500 -792@2500 -1224@2500

Electrical
Ground:	negative

Engine Detail
Isuzu E3CD
diesel
3-cylinder
liquid-cooled
Displacement:	91.4 ci 1.5 L
Bore/Stroke:	3.39x3.39 inches 86 x 86 mm
Power:	26.2 hp 19.5 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Transmission
Gears:	12 forward and reverse
Four gears in three ranges with shuttle.

Dimensions
ROPS Wheelbase:	59.1 inches 150 cm
Cab Wheelbase:	61 inches 154 cm
ROPS Length:	111.8 inches 283 cm
Cab Length:	113.8 inches 289 cm
Width:	56.3 inches 143 cm
Height (ROPS):	78.5 inches 199 cm
Height (cab):	78.4 inches 199 cm
ROPS Weight:	2877 lbs 1305 kg
Cab Weight:	3296 lbs 1495 kg
Ground clearance:	16.3 inches 41 cm
Front tread:	37.8 inches 96 cm
Rear tread:	40.6 inches 103 cm
