Mitsubishi GF14

Production: 2004 - 2005

Production
Manufacturer:	Mitsubishi
Type:	Sub-Compact Utility tractor

Mitsubishi GF14 Power
Engine:	13.3 hp 9.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Cab:	Open operator station
Transmission:	6-speed gear

Tractor hitch
Rear Type:	0
Rear lift:	1102 lbs 499 kg

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	526@2500 762@2500 1201@2500 -673@2500

Engine Detail
Mitsubishi L3C
diesel
3-cylinder
liquid-cooled
Displacement:	49.3 ci 0.8 L
Power:	13.3 hp 9.9 kW
Rated RPM:	2500
Starter:	electric
Starter volts:	12

Transmission
Type:	gear
Gears:	6 forward and 3 reverse

Dimensions
Wheelbase:	49.2 inches 124 cm
Length:	85 inches 215 cm
GF14S Width:	39.4 inches 100 cm
GF14 Width:	37 inches 93 cm
GF14S Height:	65.8 inches 167 cm
GF14 Height:	68.1 inches 172 cm
GF14S Weight:	1124 lbs 509 kg
GF14 Weight:	1168 lbs 529 kg
GF14S Ground clearance:	7.5 inches 19 cm
GF14 Ground clearance:	10.2 inches 25 cm
GF14S Front tread:	33.5 inches 85 cm
GF14 Front tread:	29.5 inches 74 cm
GF14S Rear tread:	31.1/33.1 inches 78/84 cm
G14 Rear tread:	28.4/30.3/32.3/34.3 inches 72/76/82/87 cm
