Mitsubishi GA550

Production: 2016

Production
Manufacturer:	Mitsubishi
Type:	Compact Utility tractor

Variants
GA550:	wheeled tractor
GAK550:	half-track

Mitsubishi GA550 Power
Engine:	54.4 hp 40.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Two-post ROPS. Cab optional.
Transmission:	32-speed

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift:	4220 lbs 1914 kg

Power Take-off (PTO)
Rear RPM:	4-speed (1.375)

Electrical
Ground:	negative
Battery CCA:	750
Battery volts:	12
Battery AH:	85

Engine Detail
Shibaura N4LDI-TA
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	135.2 ci 2.2 L
Bore/Stroke:	3.31x3.94 inches 84 x 100 mm
Power:	54.4 hp 40.6 kW
Fuel system:	direct injection
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Gears:	32 forward and reverse
Clutch:	wet disc

Dimensions
Wheelbase:	77.6 inches 197 cm
Length:	139.6 inches 354 cm
Width:	66.9 inches 169 cm
Height (ROPS):	98.8 inches 250 cm
Height (cab):	91.5 inches 232 cm
ROPS Weight:	4288 lbs 1945 kg
Cab Weight:	4740 lbs 2150 kg
Ground clearance:	15.2 inches 38 cm
Front tread:	49.2 inches 124 cm
Rear tread:	48 to 59.5 inches 121 to 151 cm
