McCormick Intl X50.40m

Production: 2014

Production
Manufacturer:	McCormick Intl (a part of Argo)
Type:	Utility tractor

Variants

utility

high-crop

McCormick Intl X50.40m Power
PTO (claimed):	88 hp 65.6 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	electro-hydraulic
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Trailer brakes:	hydraulic (optional)
Transmissions:	12-speed mechanical shuttle
24-speed mechanical shuttle

Hydraulics
Valves:	2
Pump flow:	13.8 gpm 52.2 lpm
Total flow:	21.6 gpm 81.8 lpm

Tractor hitch
Rear Type:	II
Control:	position and draft control
Rear lift:	5700 lbs 2585 kg
8140 lbs 3692 kg (optional)

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/750 (1.375)
540/1000 (1.375)

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Perkins 854E-E34TA
turbocharged aftercooled diesel
4-cylinder 8-valve
liquid-cooled
Displacement:	207.5 ci 3.4 L
Bore/Stroke:	3.9x4.33 inches 99 x 110 mm
Emissions:	Interim Tier 4
Emission control:	exhaust gas recirculation (EGR)
Maximum Power:	102 hp 76.1 kW
Fuel system:	direct injection
Air cleaner:	dry
Compression:	17:1
Rated RPM:	2200
Torque RPM:	1400
Starter:	electric
Starter volts:	12

Dimensions
2WD Wheelbase:	92 inches 233 cm
4WD Wheelbase:	91 inches 231 cm
Length:	162.8 inches 413 cm
Width:	81.2 inches 206 cm
Height (ROPS):	100 inches 254 cm
Height (cab):	98 inches 248 cm
Weight:	7590 lbs 3442 kg
Ground clearance:	16 inches 40 cm
Front tread:	69 to 85 inches 175 to 215 cm
Rear tread:	63 to 79 inches 160 to 200 cm
