McCormick Intl CT50U

Production: 2008 - 2010

Production
Manufacturer:	McCormick Intl (a part of Argo)
Type:	Compact Utility tractor

McCormick Intl CT50U Power
Engine:	43 hp 32.1 kW
PTO (claimed):	38 hp 28.3 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	ROPS. Cab optional.
Transmission:	16-speed

Hydraulics
Valves:	2
Pump flow:	9.1 gpm 34.4 lpm
Steering flow:	4.7 gpm 17.8 lpm

Tractor hitch
Rear Type:	I
Rear lift (at ends):	3,300 lbs 1496 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Mitsubishi
diesel
4-cylinder
liquid-cooled
Displacement:	153 ci 2.5 L
Bore/Stroke:	3.5x4.1 inches 89 x 104 mm
Power:	43 hp 32.1 kW
Air cleaner:	dry element
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Gears:	16 forward and reverse

Dimensions
Wheelbase:	74 inches 187 cm
Length:	125 inches 317 cm
Width:	65.7 inches 166 cm
Height (ROPS):	94.4 inches 239 cm
Weight:	5,005 lbs 2270 kg
Ground clearance:	14 inches 35 cm
