Massey-Harris No. 3 15-28

Production: 1922 - 1923

Production
Manufacturer:	Massey-Harris
Type:	Standard-tread tractor
Factory:	Weston, Ontario, Canada
The Massey-Harris No. 3 15-28 was based on a tractor design licensed from Parrett.

Massey-Harris No. 3 15-28 Power
Drawbar (claimed):	15 hp 11.2 kW
Belt (claimed):	28 hp 20.9 kW
Plows:	3 (14-inch)

Mechanical
Chassis:	4x2 2WD
Final drives:	spur gear
Steering:	manual
Cab:	Open operator station.
Transmission:	2-speed gear

No. 3 15-28 Serial Numbers
Location:	Inside right rear tractor fender.

Engine Detail
Buda
gasoline
4-cylinder
liquid-cooled
Displacement:	312 ci 5.1 L
Bore/Stroke:	4.25x5.50 inches 108 x 140 mm

Transmission
Type:	gear
Gears:	2 forward and 1 reverse

Dimensions
Length:	145 inches 368 cm
Width:	76 inches 193 cm
Height:	68 inches 172 cm
Weight:	5800 lbs 2630 kg
