Massey-Harris 82

Production: 1941 - 1948

Production
Manufacturer:	Massey-Harris
Original price:	$1,121 (1946)
The Massey-Harris 82 was the distillate-burning version of the 81. It was available in both standard and row-crop chassis.

Variants

row-crop gasoline

standard gasoline

distillate

Massey-Harris 82 Power
Drawbar (claimed):	16 hp 11.9 kW
PTO (claimed):	26 hp 19.4 kW

Mechanical
Chassis:	4x2 2WD
Cab:	Open operator station.
Transmission:	4-speed unsynchronized gear

Engine Detail
Continential
distillate
4-cylinder
liquid-cooled vertical L-head
Displacement:	140 ci 2.3 L
Bore/Stroke:	3.1875x4.375 inches 81 x 111 mm
Rated RPM:	1500
Starter volts:	6
Coolant capacity:	11 qts 10.4 L

Transmission
Type:	unsynchronized gear
Gears:	4 forward and 1 reverse
Clutch:	dry disc

Dimensions
Length:	119 inches 302 cm
Height:	58 inches 147 cm
Weight:	2,895 lbs 1313 kg
