Massey Ferguson 835

Production: 1958 - 1964

Production
Manufacturer:	Massey Ferguson
Type:	Utility tractor
Factory:	Beauvais, France

Massey Ferguson 835 Power
Engine:	33 hp 24.6 kW

Mechanical
Chassis:	4x2 2WD
Cab:	Open operator station.
Transmission:	6-speed gear

Power Take-off (PTO)
Rear RPM:	540 (1.375)

Engine Detail
diesel
4-cylinder
liquid-cooled
Displacement:	137.9 ci 2.3 L
Bore/Stroke:	3.31x4.00 inches 84 x 102 mm
Power:	33 hp 24.6 kW
Compression:	20:1
Rated RPM:	1800
Firing order:	1-3-4-2
Oil capacity:	7.2 qts 6.8 L

Transmission
Type:	gear
Gears:	6 forward and 2 reverse

Dimensions
Wheelbase:	72.1 inches 183 cm
Length:	116.9 inches 296 cm
Width:	63.8 inches 162 cm
Height:	53.9 inches 136 cm
Weight:	3263 lbs 1480 kg
Ground clearance:	12.6 inches 32 cm
Front tread:	48 to 80 inches 121 to 203 cm
Rear tread:	48 to 76 inches 121 to 193 cm
